Engine Type
124cc air-cooled single-cylinder four-stroke
Transmission
Five-speed manual
Front Suspension
26mm fork; 3.9-inch travel
Rear Suspension
Twin shocks; 3.6-inch travel
Seat Height
30.7 inches
Warranty
Transferable, unlimited-mileage limited warranty. One year included.
Engine
Engine Type | 124cc air-cooled single-cylinder four-stroke |
---|---|
Bore And Stroke | 50.0mm x 63.1mm |
Compression Ratio | 10.0:1 |
Valve Train | SOHC; two valves per cylinder |
Induction | PGM-FI; 24mm throttle body |
Drive Train
Transmission | Five-speed manual |
---|---|
Final Drive | #420 Chain; 14T/35T |
Chassis Suspension Brakes
Front Suspension | 26mm fork; 3.9-inch travel |
---|---|
Rear Suspension | Twin shocks; 3.6-inch travel |
Front Brake | Single 220mm hydraulic disc; ABS |
Rear Brake | 110mm mechanical drum |
Front Tire | 70/90-17 |
Rear Tire | 80/90-17 |
Dimensions
Rake | 26° |
---|---|
Trail | 2.8 inches |
Wheelbase | 48.9 inches |
Seat Height | 30.7 inches |
Fuel Capacity | 1.0 gallon |
Curb Weight | 238 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride) |
Other
Model ID | C125A |
---|---|
Emissions | Meets current EPA standards. Models sold in California meet current CARB standards and may differ slightly due to emissions equipment. |
Available Colors | Pearl Gray |
Factory Warranty Information
One Year Included | Unlimited-mileage, limited warranty |
---|---|
Optional Extended | Extended coverage available with a HondaCare Protection Plan® |
