2024 SPECIFICATIONS FourTrax Rancher

BUILD

FourTrax Rancher

FourTrax Rancher

FourTrax Rancher 4x4 Automatic DCT IRS EPS

FourTrax Rancher 4x4 Automatic DCT EPS

FourTrax Rancher 4X4 ES

FourTrax Rancher ES

FourTrax Rancher 4x4 Automatic DCT IRS

FourTrax Rancher

Engine Type

420cc liquid-cooled fuel-injected OHV wet-sump longitudinally mounted single-cylinder four-stroke
Bore And Stroke

86.5mm x 71.5mm
Compression Ratio

9.9:1
Valve Train

OHV; two valves per cylinder
Induction

Programmed Fuel Injection (PGM-FI); 34mm throttle body
Starter

Electric with optional auxiliary recoil

Clutch

Automatic
Transmission

Five-speed manual with reverse
Driveline

Direct rear driveshaft

Front Suspension

Independent double-wishbone; 6.7-inch travel
Rear Suspension

Swingarm with single shock; 6.7-inch travel
Front Brake

Dual 190mm discs
Rear Brake

160mm sealed mechanical drum
Front Tire

24 x 8-12
Rear Tire

24 x 10-11

Length

82.8 inches
Width

47.4 inches
Height

46.2 inches
Wheelbase

50.0 inches
Seat Height

33.7 inches
Ground Clearance

7.1 inches
Curb Weight

580 pounds (includes all standard equipment, required fluids and a full tank of fuel)
Fuel Capacity

3.9 gallons, including 1.3-gallon reserve
Turning Radius

9.2 feet
Front Rack Capacity

66 pounds
Rear Rack Capacity

133 pounds

Model ID

TRX420TM1
Emissions

Meets current EPA and CARB (California) off-road emissions standards.
Available Colors

Avenger Red, Black Forest Green
Important Safety Information

Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

One Year Included

Transferable, limited warranty
Optional Extended

Extended coverage available with a HondaCare®  Protection Plan

Engine Type

420cc longitudinally mounted liquid-cooled wet-sump single-cylinder four-stroke
Bore And Stroke

86.5mm x 71.5mm
Compression Ratio

9.9:1
Valve Train

OHV; two valves per cylinder
Induction

Programmed Fuel Injection (PGM-FI); 34mm throttle body
Starter

Electric with optional auxiliary recoil

Clutch

Automatic
Transmission

Five-speed automatic dual-clutch transmission with reverse
Driveline

Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential

Front Suspension

Independent double-wishbone; 7.3-inch travel
Rear Suspension

Independent dual-arm; 8.5-inch travel
Front Brake

Dual 193mm discs
Rear Brake

Dual 170mm discs
Front Tires

24 x 8-12
Rear Tires

24 x 10-12

Length

84.5 inches
Width

47.4 inches
Height

47.2 inches
Wheelbase

51.0 inches
Seat Height

35.4 inches
Ground Clearance

9.6 inches
Curb Weight

686 pounds (includes all standard equipment, required fluids and a full tank of fuel)
Fuel Capacity

3.9 gallons, including 1.3-gallon reserve
Turning Radius

11.5 feet
Front Rack Capacity

66 pounds
Rear Rack Capacity

133 pounds

Model ID

TRX420FA6
Emissions

Meets current EPA and CARB (California) off-road emissions standards.
Available Colors

Avenger Red, Black Forest Green, Sandstone Beige, Honda Phantom Camo® 
Important Safety Information

Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

One Year Included

Transferable, limited warranty
Optional Extended

Extended coverage available with a HondaCare® Protection Plan

Engine Type

420cc longitudinally mounted liquid-cooled wet-sump single-cylinder four-stroke
Bore And Stroke

86.5mm x 71.5mm
Compression Ratio

9.9:1
Valve Train

OHV; two valves per cylinder
Induction

Programmed Fuel Injection (PGM-FI); 34mm throttle body
Starter

Electric with optional auxiliary recoil

Clutch

Automatic
Transmission

Five-speed automatic dual-clutch transmission with reverse
Driveline

Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential

Front Suspension

Independent double-wishbone; 6.7-inch travel
Rear Suspension

Swingarm with single shock; 6.7-inch travel
Front Brake

Dual 190mm discs
Rear Brake

160mm sealed mechanical drum
Front Tires

24 x 8-12
Rear Tires

24 x 10-11

Length

82.8 inches
Width

47.4 inches
Height

46.2 inches
Wheelbase

50.0 inches
Seat Height

33.6 inches
Ground Clearance

7.1 inches
Curb Weight

642 pounds (includes all standard equipment, required fluids and a full tank of fuel)
Fuel Capacity

3.9 gallons, including 1.3-gallon reserve
Turning Radius

9.2 feet
Front Rack Capacity

66 pounds
Rear Rack Capacity

133 pounds

Model ID

TRX420FA2
Emissions

Meets current EPA and CARB (California) off-road emissions standards.
Available Colors

Avenger Red, Sandstone Beige, Krypton Green
Important Safety Information

Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

One Year Included

Transferable, limited warranty
Optional Extended

Extended coverage available with a HondaCare® Protection Plan

Engine Type

420cc longitudinally mounted liquid-cooled wet-sump single-cylinder four-stroke
Bore And Stroke

86.5mm x 71.5mm
Compression Ratio

9.9:1
Valve Train

OHV; two valves per cylinder
Induction

Programmed Fuel Injection (PGM-FI); 34mm throttle body
Starter

Electric with optional auxiliary recoil

Clutch

Automatic
Transmission

Five-speed manual with reverse; electric shifting
Driveline

Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential

Front Suspension

Independent double-wishbone; 6.7-inch travel
Rear Suspension

Swingarm with single shock; 6.7-inch travel
Front Brake

Dual 190mm discs
Rear Brake

160mm sealed mechanical drum
Front Tires

24 x 8-12
Rear Tires

24 x 10-11

Length

82.8 inches
Width

47.4 inches
Height

46.2 inches
Wheelbase

50.0 inches
Seat Height

33.6 inches
Ground Clearance

7.1 inches
Curb Weight

615 pounds (includes all standard equipment, required fluids and a full tank of fuel)
Fuel Capacity

3.9 gallons, including 1.3-gallon reserve
Turning Radius

9.2 feet
Front Rack Capacity

66 pounds
Rear Rack Capacity

133 pounds

Model ID

TRX420FE1
Emissions

Meets current EPA and CARB (California) off-road emissions standards.
Available Colors

Avenger Red, Black Forest Green, Sandstone Beige
Important Safety Information

Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

One Year Included

Transferable, limited warranty
Optional Extended

Extended coverage available with a HondaCare® Protection Plan

Engine Type

420cc longitudinally mounted liquid-cooled wet-sump single-cylinder four-stroke
Bore And Stroke

86.5mm x 71.5mm
Compression Ratio

9.9:1
Valve Train

OHV; two valves per cylinder
Induction

Programmed Fuel Injection (PGM-FI); 34mm throttle body
Starter

Electric with optional auxiliary recoil

Clutch

Automatic
Transmission

Five-speed manual with reverse; electric shifting
Driveline

Direct rear driveshaft

Front Suspension

Independent double-wishbone; 6.7-inch travel
Rear Suspension

Swingarm with single shock; 6.7-inch travel
Front Brake

Dual 190mm discs
Rear Brake

160mm sealed mechanical drum
Front Tires

24 x 8-12
Rear Tires

24 x 10-11

Length

82.8 inches
Width

47.4 inches
Height

46.2 inches
Wheelbase

50.0 inches
Seat Height

33.7 inches
Ground Clearance

7.1 inches
Curb Weight

580 pounds (includes all standard equipment, required fluids and a full tank of fuel)
Fuel Capacity

3.9 gallons, including 1.3-gallon reserve
Turning Radius

9.5 feet
Front Rack Capacity

66 pounds
Rear Rack Capacity

133 pounds

Model ID

TRX420TE1
Emissions

Meets current EPA and CARB (California) off-road emissions standards.
Available Colors

Avenger Red, Black Forest Green
Important Safety Information

Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

One Year Included

Transferable, limited warranty
Optional Extended

Extended coverage available with a HondaCare®  Protection Plan

Engine Type

420cc longitudinally mounted liquid-cooled wet-sump single-cylinder four-stroke
Bore And Stroke

86.5mm x 71.5mm
Compression Ratio

9.9:1
Valve Train

OHV; two valves per cylinder
Induction

Programmed Fuel Injection (PGM-FI); 34mm throttle body
Starter

Electric with optional auxiliary recoil

Clutch

Automatic
Transmission

Five-speed automatic dual-clutch transmission with reverse
Driveline

Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential

Front Suspension

Independent double-wishbone; 7.3-inch travel
Rear Suspension

Independent dual-arm; 8.5-inch travel
Front Brake

Dual 190mm discs
Rear Brake

Dual 170mm discs
Front Tires

24 x 8-12
Rear Tires

24 x 10-11

Length

84.5 inches
Width

47.4 inches
Height

47.2 inches
Wheelbase

51.0 inches
Seat Height

35.4 inches
Ground Clearance

9.6 inches
Curb Weight

668 pounds (includes all standard equipment, required fluids and a full tank of fuel)
Fuel Capacity

3.9 gallons, including 1.3-gallon reserve
Turning Radius

11.5 feet
Front Rack Capacity

66 pounds
Rear Rack Capacity

133 pounds

Model ID

TRX420FA5
Emissions

Meets current EPA and CARB (California) off-road emissions standards.
Available Colors

Avenger Red, Black Forest Green, Solstice Orange  
Important Safety Information

Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

One Year Included

Transferable, limited warranty
Optional Extended

Extended coverage available with a HondaCare® Protection Plan
