FourTrax Foreman Rubicon 4x4 Automatic DCT

1 / 1

Black Forest Green

Engine Type

518cc longitudinally mounted liquid-cooled single-cylinder four-stroke

Transmission

Five-speed automatic Dual-Clutch Transmission with reverse

Front Suspension

Independent double-wishbone; 7.3-inch travel

Rear Suspension

Independent dual-arm; 8.5-inch travel

Seat Height

36.3 inches

Warranty

Transferable, limited warranty. One year included

Extended Warranty

Engine

Engine Type	518cc longitudinally mounted liquid-cooled single-cylinder four-stroke
Bore And Stroke	96.0mm x 71.5mm
Compression Ratio	9.5:1
Valve Train	OHV; two valves per cylinder
Induction	Programmed Fuel Injection (PGM-FI); 36mm throttle body
Starter	Electric with optional auxiliary recoil

Drive Train

Clutch	Automatic
Transmission	Five-speed automatic Dual-Clutch Transmission with reverse
Driveline	Direct front and rear driveshafts with TraxLok® and locking front differential

Chassis Suspension Brakes

Front Suspension	Independent double-wishbone; 7.3-inch travel
Rear Suspension	Independent dual-arm; 8.5-inch travel
Front Brakes	Dual 190mm discs
Rear Brakes	Dual 170mm discs
Front Tires	25 x 8-12
Rear Tires	25 x 10-12

Dimensions

Length	86.0 inches
Width	47.4 inches
Height	48.7 inches
Wheelbase	50.9 inches
Seat Height	36.3 inches
Ground Clearance	9.7 inches
Curb Weight	710 pounds (includes all standard equipment, required fluids and a full tank of fuel—ready to ride)
Fuel Capacity	3.9 gallons, including 1.3-gallon reserve
Towing Capacity	1322 pounds
Front Rack Capacity	99 pounds
Rear Rack Capacity	187 pounds

Other

Model ID	TRX520FA5
Emissions	Meets current EPA and CARB (California) off-road emissions standards.
Available Colors	Black Forest Green
Important Safety Information	Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

Factory Warranty Information

One Year Included	Transferable, limited warranty
Optional Extended	Extended coverage available with a HondaCare®  Protection Plan

Download Specs

Explore further

Powerful 518cc engine

Experience unwavering performance with the robust 518cc engine, delivering the power needed on the trails and the job.

Prior Model Year Shown

Explore further

Electric reverse

Available exclusively on our automatic DCT models, this user-friendly single lever is exceptionally handy for seamless forward-to-reverse transitions—perfect for tasks like snow plowing that demand repetitive shifts.

Prior Model Year Shown

Explore further

Independent rear suspension

Independent rear suspension gives superior traction via consistent tire contact and a smoother ride over rough terrain, saving you from unnecessary trail beatings.

Explore further

TraxLok®

Experience the ultimate in traction optimization with our TraxLoks^® system. Three modes, 2WD, 4WD, and 4WD, with locking front differential and Speed Override, enable increased speed in extreme conditions like mud or snow.

Power meets precision

View all Features

Prior Model Year Shown

Preload-adjustable front and rear suspension

Enhance suspension performance for any load situation with our preload-adjustable shocks. They provide optimized functionality as you effortlessly adjust the suspension to accommodate different load conditions.

Stylish front grille

While these ATVs may be renowned for their hardworking capabilities, they also embrace a stylish appearance that sets them apart from the competition, highlighted by the aggressive front grille styling.

Prior Model Year Shown

Maxxis tires

Designed to work perfectly with the Independent Rear Suspension, the Maxxis tires feature an aggressive tread pattern for excellent traction in mud, sand, and rocky terrain.

Prior Model Year Shown

Alternator output

Thanks to the stator design, the powerful alternator produces sufficient electricity to run more Honda Accessories.

Wide front driveshaft guards

The driveshaft guards, designed to add even more coverage to the front axles and outboard CV joints, are another example of how Honda engineers sweat the small details to give you one of the best ATVs on the planet.

Prior Model Year Shown

Dual-range drive/low shifter

The DCT models feature a drive/low range in their gearbox, so you can choose the perfect gear for crawling over technical terrain, pulling heavy loads, or cruising on smoother trails.

Prior Model Year Shown

Rack capacity

This ATV has sporty, strong steel racks: The front rack capacity is 99 pounds, and the rear rack can hold up to a whopping 187 pounds. Multiple tie-down points also make it easier than ever to secure your loads.
