2024 SPECIFICATIONS FourTrax Recon

BUILD

FourTrax Recon

FourTrax Recon

FourTrax Recon ES

FourTrax Recon

Engine Type

229cc air-cooled OHV longitudinally mounted single-cylinder four-stroke
Bore And Stroke

68.5mm x 62.2mm
Compression Ratio

9.2:1
Induction

OHV; two valves per cylinder
Induction

22mm piston-valve carburetor
Starter

Electric with optional auxiliary recoil

Transmission

Five-speed ATV-style semi-automatic with reverse
Driveline

Direct rear driveshaft

Front Suspension

Independent double-wishbone; 5.1-inch travel
Rear Suspension

Swingarm with single shock; 4.9-inch travel
Front Brake

Dual sealed 130mm drums
Rear Brake

Sealed 140mm drum
Front Tires

22 x 7-11
Rear Tires

22 x 10-9

Length

75.0 inches
Width

40.7 inches
Height

42.1 inches
Wheelbase

44.5 inches
Seat Height

31.2 inches
Ground Clearance

6.0 inches
Turning Radius

8.5 feet
Curb Weight

437 pounds (Includes all standard equipment, required fluids and a full tank of fuel)
Fuel Capacity

2.4 gallons, including 0.6-gallon reserve
Front Rack Capacity

33 pounds
Rear Rack Capacity

66 pounds
Towing Capacity

500 pounds

Available Colors

Avenger Red, Black Forest Green, Krypton Green
Model ID

TRX250TM
Emissions

Meets current EPA off-road emissions standards. Not available in California or for California use.
Important Safety Information

Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

One Year Included

Transferable, unlimited-mileage warranty
Optional Extended

Extended coverage available with a HondaCare Protection Plan®

Engine Type

229cc air-cooled OHV longitudinally mounted single-cylinder four-stroke
Bore And Stroke

68.5mm x 62.2mm
Compression Ratio

9.2:1
Valve Train

OHV; two valves per cylinder
Induction

22mm piston-valve carburetor
Starter

Electric with optional auxiliary recoil

Transmission

Five-speed with reverse; electric shifting
Driveline

Direct rear driveshaft

Front Suspension

Independent double-wishbone; 5.1-inch travel
Rear Suspension

Swingarm with single shock; 4.9-inch travel
Front Brake

Dual sealed 130mm drums
Rear Brake

Sealed 140mm drum
Front Tires

22 x 7-11
Rear Tires

22 x 10-9

Length

75.0 inches
Width

40.7 inches
Height

42.1 inches
Wheelbase

44.5 inches
Seat Height

31.2 inches
Ground Clearance

6.0 inches
Turning Radius

8.5 feet
Curb Weight

443 pounds (Includes all standard equipment, required fluids and a full tank of fuel)
Fuel Capacity

2.4 gallons, including 0.6-gallon reserve
Front Rack Capacity

33 pounds
Rear Rack Capacity

66 pounds
Towing Capacity

500 pounds

Available Colors

Avenger Red, Black Forest Green, Krypton Green
Model ID

TRX250TE
Emissions

Meets current EPA off-road emissions standards. Not available in California or for California use.
Important Safety Information

Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

One Year Included

Transferable, unlimited-mileage warranty
Optional Extended

Extended coverage available with a HondaCare Protection Plan®
