FourTrax Recon ES
229cc air-cooled OHV longitudinally mounted single-cylinder four-stroke
Five-speed with reverse; electric shifting
Independent double-wishbone; 5.1-inch travel
Swingarm with single shock; 4.9-inch travel
31.2 inches
Engine
| Engine Type | 229cc air-cooled OHV longitudinally mounted single-cylinder four-stroke |
|---|---|
| Bore And Stroke | 68.5mm x 62.2mm |
| Compression Ratio | 9.2:1 |
| Valve Train | OHV; two valves per cylinder |
| Induction | 22mm piston-valve carburetor |
| Starter | Electric with optional auxiliary recoil |
Drive Train
| Transmission | Five-speed with reverse; electric shifting |
|---|---|
| Driveline | Direct rear driveshaft |
Chassis Suspension Brakes
| Front Suspension | Independent double-wishbone; 5.1-inch travel |
|---|---|
| Rear Suspension | Swingarm with single shock; 4.9-inch travel |
| Front Brake | Dual sealed 130mm drums |
| Rear Brake | Sealed 140mm drum |
| Front Tires | 22 x 7-11 |
| Rear Tires | 22 x 10-9 |
Dimensions
| Length | 75.0 inches |
|---|---|
| Width | 40.7 inches |
| Height | 42.1 inches |
| Wheelbase | 44.5 inches |
| Seat Height | 31.2 inches |
| Ground Clearance | 6.0 inches |
| Turning Radius | 8.5 feet |
| Curb Weight | 443 pounds (Includes all standard equipment, required fluids and a full tank of fuel) |
| Fuel Capacity | 2.4 gallons, including 0.6-gallon reserve |
| Front Rack Capacity | 33 pounds |
| Rear Rack Capacity | 66 pounds |
| Towing Capacity | 500 pounds |
Other
| Available Colors | Hero Red, Black Forest Green |
|---|---|
| Model ID | TRX250TE |
| Emissions | Meets current EPA off-road emissions standards. Not available in California or for California use. |
| Important Safety Information | Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly. |
Factory Warranty Information
| One Year Included | Transferable, limited warranty |
|---|---|
| Optional Extended | Extended coverage available with a HondaCare® Protection Plan |
Explore smarter
Effortless shifting, endless exploring
Semi-dry-sump engine design
The overhead-valve, semi-dry-sump design creates a compact and lightweight engine that improves handling by lowering the center of gravity and increasing ground clearance.
Longitudinal engine layout
By orienting the crankshaft front to back in the chassis, we route the power flow straight to the wheels without any unnecessary right-angle detours, reducing powertrain friction and putting more grunt to the ground.
Effortless electric starting
Starting the engine is easy, even in cold weather, with a key turn or a button push. A backup recoil starting system is included for added confidence.
Shaft drive
The shaft drive is clean, low-maintenance, and efficient, perfect for high-mileage riders. It eliminates the need for lubrication or adjustment on the trail.
Precision at your fingertips
Electric Shift Program (ESP)
Found on the ES model, the ESP system features easy upshifting and downshifting with a push-button. No foot-shift lever is needed, making it great when riding in mud/snow-covered boots.
Reverse mechanism and parking brake
The reverse lever, mounted on the left bar alongside the parking brake, is easy to use without taking your hands off the handlebar.
Comfortable seat
A thick foam seat with a rugged cover is designed for all-day comfort and support.
Steel cargo racks
The front and rear cargo racks feature rugged steel construction, and can carry a maximum of 33 pounds (front) and 66 pounds (rear).
LED taillight and brakelight
The taillight and brakelight are both LED, designed to last long and offer dependable lighting.
Unique floorboard design
The floorboards are designed to prevent mud and debris while providing a good grip on the rider's feet.
