Rebel 500 ABS SE
471cc liquid-cooled parallel-twin four-stroke
Six-speed manual
41mm fork; 5.5-inch travel
Dual shocks, 3.7-inch travel
27.2 inches
Transferable, unlimited-mileage limited warranty. One year included.
Engine
| Engine Type | 471cc liquid-cooled parallel-twin four-stroke |
|---|---|
| Bore And Stroke | 67.0mm x 66.8mm |
| Induction | Programmed Fuel Injection (PGM-FI); 34mm throttle body |
| Valve Train | DOHC; 4 valves per cylinder |
| Compression Ratio | 10.7:1 |
Drive Train
| Transmission | Six-speed manual |
|---|---|
| Final Drive | O-ring-sealed chain; 15T/40T |
Chassis Suspension Brakes
| Front Suspension | 41mm fork; 5.5-inch travel |
|---|---|
| Rear Suspension | Dual shocks, 3.7-inch travel |
| Front Brake | Single 296mm disc; ABS |
| Rear Brake | Single 240mm disc; ABS |
| Front Tire | 130/90-16 |
| Rear Tire | 150/80-16 |
Dimensions
| Rake | 28.0° |
|---|---|
| Trail | 4.3 inches |
| Wheelbase | 58.7 inches |
| Seat Height | 27.2 inches |
| Curb Weight | 416 pounds (Includes all standard equipment, required fluids and a full tank of fuel) |
| Fuel Capacity | 3.0 gallons |
Other
| Model ID | CMX500A2 |
|---|---|
| Emissions | Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment. |
| Available Colors | Pearl Smokey Grey |
Factory Warranty Information
| One Year | Transferable, unlimited-mileage limited warranty |
|---|---|
| Optional Extended | Extended coverage available with a HondaCare® Protection Plan |
Redefine the streets
Exclusive all the way around
Blacked-out style
The Rebel is ready for you to unleash your creativity. It's a canvas of self-expression that's impressive by day and at night, a masterpiece.
Low seat height
In the realm of seat heights, lower reigns supreme. This bike flaunts one of the lowest at 27.2 inches for maximum rider comfort and easy flat-footing at lights or in parking lots.
Slipper clutch
We've reduced clutch effort by nearly 30 percent. Born from Honda's racing pedigree, the perfected slipper clutch delivers a feather-light pull at the lever and steadfast lock-out when power meets the road.
Sporty engine
Celebrated for its versatility, the narrow parallel-twin engine masters size reduction while delivering big low-rpm torque and thrilling high-rpm performance.
Your personal escape pod
Limited-edition 500 ABS SE
With handpicked factory-installed accessories – black diamond-stitch seat, black fork boots and upper covers, and black headlight cowl – this Special Edition will sell out fast.
Front and rear disc brakes w/ABS
The 500 ABS and Special Edition trims get front and rear disc brakes with our Anti-Lock Braking System (ABS) as standard, giving you excellent linear stopping power for supreme confidence in the most challenging conditions.
Wide fork
The fat 41mm fork tubes offer precise steering, a plush ride, and enhance the bike's substantial presence. Plus, the unique titanium oxide finish gives it that sleek blacked-out look.
Premium rear suspension
Equipped with nitrogen-filled remote-reservoir shocks and custom spring rates, the rear shocks on these bikes provide the perfect blend of comfort and performance.
Roomy rider triangle
The ideal balance of relaxed cruiser comfort and dynamic sport riding engagement can be experienced through the thoughtfully crafted rider triangle.
Narrow overall width
The remarkable slimness of the bike, particularly at the crucial tank/seat junction, ensures effortless mounting and dismounting, as well as confident footing at every stop.
All-LED lighting package
When it comes to lighting, the Rebel lineup embraces an all-LED setup, offering lighter, brighter, and longer-lasting illumination throughout its entire package.
Classic round headlight
The three-inch, round nacelle headlight is a key element in the motorcycle's design, contributing to the bike's timeless character.
Modern/classic instrument shape
The instruments merge classic design with modern reverse-image digital LCD technology, providing a comprehensive display of information, including speed, gear position, fuel level, and engine modes.
Passenger seat and footpeg kit
You can easily configure your bike for solo journeys or passenger comfort with simple, bolt-on features like removable seat rails, an optional passenger seat, and passenger footpegs.
