2009 Rebel Specifications - Honda Powersports

Specifications

Engine

Engine
Engine Type	234cc air-cooled parallel twin-cylinder	Smooth, quiet and economical, the Rebel’s proven 234cc parallel twin powerplant is a model of bulletproof reliability and user-friendliness.
Bore And Stroke	53.0mm x 53.0mm
Induction	Single 26mm diaphragm-type constant-velocity (CV) carburetor
Ignition	CD
Compression Ratio	9.2:1
Valve Train	SOHC; two valves per cylinder

Drive Train

Drive Train
Transmission	Five-speed	With its smooth shifting action and rider-friendly ratios, the five-speed transmission is a dream for entry-level and experienced riders alike.
Final Drive	O-ring sealed chain

Chassis / Suspension / Brakes

Chassis / Suspension / Brakes
Front Suspension	33mm fork; 4.6-inch travel	A hydraulic fork teams with dual rear shocks (with five-way spring preload adjustability) for a plush ride and light, responsive steering.
Rear Suspension	Dual shocks with five-position spring-preload adjustability; 2.9-inch travel	A hydraulic fork teams with dual rear shocks (with five-way spring preload adjustability) for a plush ride and light, responsive steering.
Front Brake	Single-disc with twin-piston caliper
Rear Brake	Drum
Front Tire	3.00-18
Rear Tire	130/90-15

Dimensions

Dimensions
Rake	30-degree 40'
Trail	113mm (4.4 inches)
Wheelbase	57.1 inches
Seat Height	26.6 inches	The Rebel’s semi-double-cradle frame construction helps permit a low, 26.6inch seat height, inspiring even greater rider confidence.
Curb Weight	331 lbs (Includes all standard equipment, required fluids and a full tank of fuel-ready to ride)
Fuel Capacity	2.6 gallons, including 0.7-gallon reserve

Other

Other
Available Colors	Black, Ultra Blue Metallic
Model Id	CMX250C
Emissions	Meets Current EPA standards. California version differs slightly due to emissions equipment.

FACTORY WARRANTY INFORMATION

FACTORY WARRANTY INFORMATION
One Year	Transferable one-year unlimited-mileage warranty; extended coverage available with a Honda Protection Plan
